Our Cranes

Our cranes are fast, accurate and reliable. Below you can see our brochure and catalog as well as download lift charts.
See brochureSee catalog

SPIERING CRANES

Our Spiering cranes are mobile tower cranes and are one-man operated, the cranes are space-saving and even carry all counterweight and support legs.

The cranes can be operated via remote control or from the cab at the top of the crane.

From the crane driver’s seat there is a fantastic view of the construction site, and a camera is mounted on the trolley letting the crane driver monitor the task via a screen.

44 meter

  • 44 meters reach
  • Max load is 8 tons at 12.8 meters
  • It lifts 1900 kg at 44 meters reach
  • Max lift height is 46 meters with the jib tilted up 30 degrees

Layout: L = 7000 x W = 7000 mm
Axle pressure: 12 tons
Total weight: 48 tons
Max support leg pressure: 36 tons

See diagram

50 meter

  • 50 meter reach
  • Max load is 9 tons at 13 meters
  • It lifts 1900 kg at 50 meters reach
  • Max lift height is 55 meters with the jib tilted up 30 degrees

Layout: L = 7500 x W = 8500 mm
Axle pressure: 12 tons
Total weight: 60 tons
Max support leg pressure: 45 tons

See diagram

60 meter

  • 60 meter reach
  • Max load is 10 tons at 13.2 meters
  • It lifts 1700 kg at 60 meters reach
  • Max lift height is 65 meters with the jib tilted up 30 degrees

Layout: L = 8000 x W = 9000 mm
Axle pressure: 12 tons
Total weight: 72 tons
Max support leg pressure: 52 tons

See diagram

38 meter crawler crane

  • 38 meter reach
  • Max load is 8 tons at 12.8 meters
  • It lifts 1700 kg at 38 meters reach
  • Max lift height is 42 meters with the jib tilted up 30 degrees

Layout: L = 7000 x W = 7500 mm
Total weight: 52 tons
Max support leg pressure: 33 tons

See diagram
